Creo+ Ansys Simulation Advanced - Subscription

Creo+ Ansys Simulation Advanced - Subscription


Overview

Creo Ansys Simulation and Creo Ansys Simulation Advanced are simulation tools for designers and engineers. They integrate Ansys' advanced capabilities for thermal, structural, and modal analyses into Creo, providing an easy-to-use, high-fidelity simulation solution that supports design refinement and validation.

Creo Ansys Simulation allows for early insight into product behavior, reducing costs, and speeding time to market. The advanced extension Creo Ansys Simulation Advanced provides even more benefits to users. With Creo Ansys Simulation Advanced, engineers can now run multiphysics studies. Users can now easily run structural and thermal studies together to model thermal expansion. It also provides powerful and robust contact options, expanding use cases for nonlinear contact and nonlinear materials.


Which version of Creo ANSYS Simulation is right for you?


Capabilities


Creo Ansys Simulation


Creo Ansys Simulation Advanced
Static Structural Analysis ✔ ✔
Finite Element Modeling
Idealization		 ✔ ✔
Automatic Meshing ✔ ✔
Results Display & Reporting ✔ ✔
H-Element Technology ✔ ✔
Modal Analysis ✔ ✔
Steady State Thermal Analysis ✔ ✔
Linear Contact Analysis  ✔ ✔
Large Deformation ✔ ✔
Midsurface Shell Compression ✔ ✔
Joints ✔ ✔
Non-Linear Contact
✔
Non-Linear Materials
✔
Transient Structural
✔
Combined Structural/Thermal
✔


Key Features and Benefits
  • Powered by Ansys, with high-fidelity, high-accuracy simulation for design refinement and validation
  • Linear Static Structural Analysis, Modal Structural Analysis, and Steady State Thermal Analysis
  • Support for transient structural simulation (time dependent boundary conditions)
  • Multiple studies per simulation model
  • Automatic mesh and contacts (advanced options for manual control)
  • Support for non-linear contact and non-linear materials (only available in the Advanced version)
  • Support for masses, springs, shells, and beams
  • Boundary conditions specified on geometry
  • Associativity with Creo Simulation Live Setup


Features


Structural Boundary Conditions

• Fixed Support
• Enforced Translations and Rotations (Optional - apply from a remote point)
• Planar, Cylindrical, Ball and Frictionless Constraints
• Force Load
     • Specified in terms of total or per unit area
     • Total load at a point
• Moment Load
• Pressure Load
• Bearing Load
• Gravity Load
• Centrifugal Loads specified by the angular velocity or angular acceleration of the structure
• Temperature Load
• Linear Acceleration Load
• Inertia relief support

Thermal Boundary Conditions

• Boundary Conditions specified on geometry
• Prescribed Temperature
• Convection Condition
• Radiation Condition
• Heat Flow
• Heat Flux
• Heat Generation

Results

• Basic and Advanced results
• Result Window Templates
• Full Results post-processing
• On full model or selected geometry
     • Fringes, Contours, Iso-surfaces
     • Large variety of contour plots
     • Vector Plots
     • Animation
• Simulation Probes
• At Point
     • Maximum/Minimum/Average/Sum over Model
     • Maximum/Minimum/Average/Sum over Selected Geometry
     • Control over units
     • Saved with results
     • Simulation tree support
• Update results after new result definitions
• Simulation Query
• Active measuring based of legend selection
     • Save option
• Launch Results in Auxiliary window

Meshing, Element Types and Idealizations

• Automated Physics-aware and part based meshing process
• Hexahedral and tetrahedral elements automatically created
• Mesh resolution slider bar to control fidelity in results
• Local mesh refinement
• Body, face and edge sizing supported
• Global mesh size options (all with respective size values)
• Curvature
     • Proximity
• Fixed
• Shell definition and support
• Mid-surface creation
• Automatic connections of shell elements
• Multiple beam sections and properties
• Beam releases
• General specification of Beam Section
     • Orientation
     • Beam release
• Constant Stiffness Springs
• 1D and 3D
     • Torsional and longitudinal
     • Optional Preload
     • Fix to ground
• Point Masses
Connections

• Contact Interfaces
• Automatic or manual contact definition
     • Multi-surface to multi-surface definition
     • Bonded or no separation types
• Joints
• Geometry based definition (edges, points and surfaces)
     • References to ground
• Multiple types
 • Fixed, hinge, translational, slot, cylindrical, universal, spherical and planar
General Modeling Tools

• Units Manager - Commonly used units for all quantities available
• Creation of custom units and unit systems
• Model definition in user selected units
• Results in user selected units
• Surface Regions
• Defined by sketch or curves
• Coordinate Systems
• History-based, associative, parametric features
• User defined Cartesian coordinate systems
• Typical metals and plastics included
• Storage of user defined materials
Process Tools

• Creo Ansys Model is an integral part of CAD model
     and fully supported by Windchill® (WC 12.1)
• Results optionally uploaded to Windchill
     and automatically associated to the model (WC 12.1)
• 4-Core parallel solution solver
• Export to Ansys Workbench/Mechanical
• Save APR format
     • Archive that contains the model and simulation data
Non-Linear Contact
Available in Advanced only

• New contact types
     • Frictional, frictionless and rough
• Contact Behavior can be specified
     • Grouping of contacts
• Additional Settings
     • Formulation
     • Detect contacts by radius or factor
     • Stiffness factor and more
• Preview Simulation for all contact options
• Corresponding contact related results
• Creo Ansys Advanced license required
Non-Linear Materials
Available in Advanced only

• Neo-Hookean hyperelasticity
• Usable for plastics and rubber materials
     • Non linear stress strain behavior with large deformations
• Linear orthotropic elasticity
• Includes transverse isotropic material
     • Usable for woods, rolled materials and any material that depends on direction
• Bi-linear plasticity
• Usable in large strain analysis
     • Defined using ‘Linear Hardening’ option in material definition
• Creo Ansys Advanced license required

Combined Structural and Thermal
Available in Advanced only

Transient Structural
• Combined physics of Thermal and Structural
     • Thermal expansion use case
• Primary study can be thermal or structural
     • Then add additional physics
     • Additional physics are added to ribbon
     • Can be switched off and return to primary physics
• Only available as steady-state thermal study
• Creo Ansys Advanced license required

Transient Structural
Available in Advanced only

• Combined physics of Thermal and Structural
     • Thermal expansion use case
• Primary study can be thermal or structural
     • Then add additional physics
     • Additional physics are added to ribbon
     • Can be switched off and return to primary physics
• Only available as steady-state thermal study
• Creo Ansys Advanced license required
• Time dependent structural simulation—Loads are function of time
• Additional Simulation Setup options
     • Initial Velocity
     • Damping
     • Step Duration
     • Sub-Stepping
     • Based on (time)
• Define constraints as functions of time
• Results graphs
• From all contour plots
     • From all probes



Trial Download


PTC Creo Free Trial Software Download


Download and test PTC Creo before you make your purchasing decision.



$24,000.00
Creo+ Ansys Simulation Advanced - Subscription—
$24,000.00
