Creo+ EZ Tolerance Analysis Extension - Subscription
OverviewBased on CETOL Technology, the PTC Creo Tolerance Analysis Extension (TAE) enables the rapid analysis and documentation of geometric tolerances directly in the 3D CAD model, so that after manufacture all components of the product fit together correctly.
Creo Tolerance Analysis Extension provides a powerful tolerance stack-up and gap analysis solution that is seamlessly integrated into the Creo design environment. The graphical user interface is easy to learn and use. You can evaluate the impact of tolerances and dimensioning schemes on the feasibility of product designs, without tedious spreadsheet analysis. In addition, any change made to the design is automatically reflected in all downstream deliverables – without risk of translation errors in your design. The result: shorter product development cycles, lower product cost, and higher product quality.
|
|
Key benefits
- Evaluate the impact of tolerances on the manufacturability of designs
- Enable concurrent engineering to ensure designs meet manufacturing requirements
- Six Sigma design methodologies to ensure design quality
- Streamline design processes, improve productivity, and reduce time-to-market
Capabilities and specifications
Easy-to-use capabilities
- Integrated graphical user interface is easy to learn and use
- 1D tolerance loops
- Tolerance stack-ups
- Automatic validation of dimensions and dimension loop
- Interactive visualization of the tolerance loop
- Profile and position GTOLS supported
- Tolerance analyses can be saved as a feature in PTC Creo
- Part of assembly-level management of tolerance analyses
- Quickly edit analysis inputs by deleting or substituting components and dimensions
Powerful analysis
- Contribution and sensitivity analysis
- Configurable biasing of pin/hole joints
- Worse-case and statistical analysis
- Reference driving as well as annotation dimensions
- Placeholder components enable simulation of dimension properties that are not accounted for in the CAD model
- Automatically closes gaps in the model
Results
- Contribution and sensitivity output plots
- Automatically generated HTML results report
- View worst case and statistical distributions
- Mean and standard deviation
- Dynamic display of results within the Tolerance Analysis Feature
- Results such as sigma defects per million units (DPMU) and % yield can be saved as parameters in the Tolerance Analysis feature
Trial Download
PTC Creo Free Trial Software Download
Download and test PTC Creo before you make your purchasing decision.
Select Options
From $426.00
Original: $1,420.00
-70%Creo+ EZ Tolerance Analysis Extension - Subscription—
$1,420.00
$426.00
